4130 All-Road - Root Beer (12 Speed / UDH)
The 4130 All-Road is built for riders who want to do everything — gravel races, bikepacking missions, commutes, trail days — without buying multiple bikes or compromising on any of them. A fully revamped 4130 Chromoly Steel frame with UDH compatibility, dropper-post readiness, semi-internal cable routing, and mounts for bottles, racks, fenders, and accessories gives you a platform that can be set up for almost anything.
Platform Highlights
- 4130 Chromoly Steel Frame — Tough, repairable, and with a ride quality that carbon can't replicate. Built for the long haul.
- UDH-Compatible — Universal Derailleur Hanger means no hunting for proprietary parts anywhere in the world.
- Dropper Post Ready — Internal routing already in place. Add a dropper whenever you're ready.
- Semi-Internal Cable Routing — Cleaner than fully external, easier to service than fully internal.
-
Tire Clearance — Plenty of room for real-world rubber in any configuration:
- Frame & Standard Fork: 700c x 55mm (2.25") or 650b x 60mm (2.4")
- Frame & Monster Fork (Carbon): 700c x 55mm (2.25") or 650b x 50mm (2.25")
- Mounts for Everything — 3 water bottle mounts plus rack, fender, and accessory mounts. Pack it up or strip it down.
Build & Customize
Wheelset — choose your build
💡 Want both? Add the dual wheelset option — wheels, tires, tubes, rotors, and cassette — for $299.99. Swap between setups in minutes.
Fork — choose your setup
Complete Component Spec
Frame
- 4130 Chromoly Steel with Thru-Axle Dropouts (142mm rear spacing)
- UDH-Compatible derailleur hanger
- Semi-Internal Cable Routing
- Dropper Post Ready
- Mounts for 3 water bottles, racks, fenders, and accessories
Drivetrain
- 12-Speed State Bicycle Co. drivetrain
- Crank: 40t Direct Mount Chainring
- Cassette: 11–46t (upgrade to 11–50t available for $69.99)
Cockpit & Brakes
- Gravel handlebar with 33° flare
- Cable-Actuated Hydraulic Disc Brakes with compressionless housing
- Note: SRAM drivetrain upgrades include full hydraulic brakes
Rims
- 700c: 23mm tubeless-capable (tape, valves, and sealant required)
- 650b: 25mm tubeless-capable (tape, valves, and sealant required)
Tires
- 700c: Continental Terra Hardpack TR 50mm — tubeless ready
- 650b: Vittoria Barzo 2.1" — not tubeless rated
⚠️ Please note: the Vittoria Barzo tires (650b) are not rated tubeless. While it may be possible to set these up tubeless, we cannot guarantee compatibility. State Bicycle Co. recommends professional assembly for tubeless setups.
Available Upgrades
Drivetrain
Wheels
- Dual Wheelset (700c + 650b) — $299.99. Both wheel sizes, both tire setups, rotors, cassette, and tubes included.
- DT Swiss Alloy Wheelset — +$450. Available in 650b or 700c. A meaningful step up in stiffness, weight, and hub quality.
- Zipp Carbon Wheelsets — Starting at $965 (reg. $1,400). Tubeless only, sealant included. The fastest wheel upgrade available for this build.
Size Recommendations
- XS: 5'1" – 5'6"
- S: 5'5" – 5'10"
- M: 5'9" – 6'2"
- L: 6'1" – 6'5"
Want to get technical? Full Geo / Specs here.
